Canon imagePROGRAF iPF810 User Manual

Problems with the printing quality
Colors in printed images are uneven
Cause Corrective Action
Line Drawing/T ext is selected when printing images
in many solid colors.
Specify Image in the printer driver .
Y ou are printing on paper that curls easily . Printed colors may appear uneven on the leading
edge of paper that is susceptible to curling. Increase
the level of vacuum holding the paper against the
Platen or specify a margin of 20 mm (0.79 in.) or
more for the leading edge.
( → P .571)
Printed colors may be uneven if you set the Print
Quality too low .
Choose a higher level of Print Quality in the
Advanced Settings of the printer driver .
Printing in Draft or Standard mode is faster and
consumes less ink than in Highest or High modes,
but the printing quality is lower .
( → P .222)
Color may be uneven between dark and light image
areas.
Select Unidirectional Printing in the Advanced
Settings of the printer driver .
Specify No in Auto Cut in the printer driver before
printing. In this case, the paper can be printed without
borders on the left and right sides only . Cut the
printed document ejected from the printer , then use
scissors to cut away the edges on the top and bottom.
When borderless printing is used, the edge of the
paper is cut during printing. Thus, ink density may
be uneven at the edges.
Choose a higher level of Print Quality in the
Advanced Settings of the printer driver .
( → P .222)
The Printhead is out of alignment. Adjust the Printhead alignment.
( → P .554)
Drying documents stacked on each other may cause
uneven colors.
T o avoid uneven colors, we recommend drying each
sheet separately .
Color density may be uneven if you use Glossy
Paper , art paper , or Coated Paper .
In Advanced Settings of the printer driver , choose
Highest or High in Print Quality .
Load paper of the same type as you have specied
in the printer driver .
( → P .139)
( → P .164)
The type of paper specied in the printer driver does
not match the type loaded in the printer .
Make sure the same type of paper is specied in the
printer driver as you have loaded in the printer .
1. Hold down the Stop button for a second or more
to cancel printing.
2. Change the type of paper in the printer driver and
try printing again.
T roubleshooting 637

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
