Canon imagePROGRAF iPF810 User Manual

Ink T anks
Replacing Ink T anks
Compatible ink tanks
Replacement ink tanks in 330 ml (1 1.2  oz) and 700 ml (23.7  oz) capacities are supported.
These ink tanks are labeled with a white letter “A” in a black circle on the side. Request ink tanks with the
same label when you purchase new ones. For details, see “Ink T anks”. (→P .572)
Precautions when handling ink tanks
T ake the following precautions when handling ink tanks.
Caution
• For safety , keep ink tanks out of the reach of children.
• If ink is accidentally ingested, contact a physician immediately .
Important
• When it is time to install ink tanks, before opening the pouch tilt the tank to the left and right gently seven
or eight times. If you do not agitate the Ink T ank , the ink may sediment, which may af fect printing quality .
• Do not remove and agitate ink tanks that have already been installed in the printer . Ink may leak out.
• A void dropping the Ink T ank after removing it from the pouch. Otherwise, ink may leak and cause stains.
• There may be ink around the ink supply section of ink tanks you remove. Handle ink tanks carefully
during replacement. The ink may stain clothing.
• W e recommend using up an Ink T ank in the course of printing within six months after breaking the seal.
Printing quality may be af fected if you use older ink tanks.
• Do not leave the printer without ink tanks installed for extended periods (a month or more). Residual ink
may become clogged inside the printer and af fect printing quality .
• If you pause printing to replace an ink tank, it may cause uneven colors in the printed image.
How to replace an Ink T ank
1. Make sure the printer is ready for Ink T ank replacement. (→P .574)
2. Access the menu for Ink T ank replacement. (→P .574) (Otherwise, open the Ink T ank Cover .)
3. Remove the Ink T ank .
• 330 ml ink tanks (→P .575)
• 700 ml ink tanks (→P .577)
4. Load the new Ink T ank .
• 330 ml ink tanks (→P .579)
• 700 ml ink tanks (→P .581)
Maintenance 573

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
