Canon imagePROGRAF iPF810 User Manual

Printer Driver
Mac OS X Software
Printer Driver
Printer Driver Settings (Mac OS X)
For instructions on accessing the Mac OS X printer driver , refer to the following topics.
• Accessing the Printer Driver Dialog Box from Applications (Mac OS X) (→P .435)
For information on the Mac OS X printer driver settings, refer to the following topics.
• Main Pane (Mac OS X) (→P .436)
Y ou can specify the media type, color processing, print quality , print preview , and other settings. Choose
Easy Settings to specify basic print settings based on the printing application or Advanced Settings
to complete more detailed settings as desired.
• Media Detailed Settings Dialog Box (Mac OS X) (→P .440)
• V iew Settings Dialog Box for the Printing Application (Mac OS X) (→P .441)
• Color Settings Pane: Color (Mac OS X) (→P .442)
• Color Settings Pane: Monochrome (Mac OS X) (→P .444)
• Page Setup Pane (Mac OS X) (→P .445)
Y ou can specify the page size of the original, borderless printing, enlargement or reduction, the
orientation, the paper size and source, and automatic cutting.
• Utility Pane (Mac OS X) (→P .447)
Y ou can specify settings related to maintenance for the Printhead and feed amount, as well as settings
for Color imageRUNNER Enlargement Copy .
• Additional Settings Pane (Mac OS X) (→P .448)
Y ou can specify settings for how print jobs are sent to the printer .
• Support Pane (Mac OS X) (→P .449)
Y ou can view support information and the user ’ s manual.
With the imagePROGRAF Free Layout feature, you can arrange originals from various source applications
on a single page before printing. For details, see Free Layout .
With the imagePROGRAF Preview feature, you can check the layout before printing and adjust layout or
size settings while viewing a preview screen. For details, see Preview .
With the Color imageRUNNER Enlargement Copy feature, you can automatically enlarge and print scanned
originals from a Color imageRUNNER . For details, see Color imageRUNNER Enlargement Copy .
428 Mac OS X Software

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
