Messages regarding the hard disk
Messages regarding the hard disk
Hard disk error .
Cause Corrective Action
The format of the printer s hard disk is invalid. Press the OK button to start reformatting the
hard disk. When formatting is nished, the printer
automatically restarts. (Formatting will erase all data
on the hard disk.)
File read error .
Cause Corrective Action
Files on the printer s hard disk have become
corrupted.
Restart the printer . Only the corrupted les will be
deleted, and the printer will restart.
The mail box is full.
Cause Corrective Action
Press the Stop button to cancel the print job.
Delete print jobs from the queue.
( P .500)
There is no more space on the printer s hard disk.
Delete unneeded jobs stored in personal boxes (box
numbers in the range 01-29).
( P .544)
Mail box full. Now printing without saving data.
Cause Corrective Action
No more space is available on the printer s hard disk,
so jobs are now printed without saving them. (Print
jobs can no longer be saved on the hard disk.)
After printing, this message is cleared.
Mail box nearly full.
Cause Corrective Action
The free hard disk space left for personal boxes in the
printer s hard disk does not have 1 GB, combined.
Delete unneeded jobs stored in personal boxes.
( P .544)
680 Error Message
