Printing Of ce Documents
Printing Ofce Documents
Printing Ofce Documents
Printing is easy when you simply choose the type of original to print.
Easy Settings
Simply choose the printing application in the list for optimal printing results.
Print T arget
Choose presets that match the type of document to be printed.
Print targets for ofce documents
Print T arget
Description
Of ce Document Settings optimized for clear printing of of ce
documents such as handouts.
Note
Y ou can check the settings values for each print target by clicking V iew Settings .
Y ou can also ne-tune these values as needed. (Advanced Settings)
For details on Advanced Settings, see “Giving Priority to Particular Graphic Elements and Colors
for Printing”. (→P .222)
For instructions on printing of ce documents, refer to the following topics, as appropriate for your computer
and operating system.
Printing Of ce Documents (Windows) (→P .203)
Printing Of ce Documents (Mac OS X) (→P .205)
202 W orking With V arious Print Jobs

Table of Contents

Other manuals for Canon imagePROGRAF iPF810

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF810 and is the answer not in the manual?

Canon imagePROGRAF iPF810 Specifications

Print Specifications IconPrint Specifications
print resolution2400 x 1200 dpi
line accuracy±0.1% or Less
minimum line weight0.02 mm
number of nozzles (Matte Black)5, 120 Nozzles
number of nozzles (Other Colors)2, 560 Nozzles per Color
droplet size4 Picoliter
nozzle pitch (head resolution)1200 dpi x Two Rows
print-head swath1.07 inch
Ink and Media IconInk and Media
ink type (Dye)Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)Matte Black (MBK)
ink tank shipped with printerPFI-303 (330ml) MBK, C, M, Y, K
ink tank replacementPFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)10" – 44" (254mm – 1118mm)
media width (Cut Sheet)8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)59' (18m)
maximum print length (Cut Sheet)63" (1.6m)
media thickness0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter5.9" (150mm)
Power and Noise IconPower and Noise
power supplyAC 100–240V (50-60Hz)
power consumption (Maximum)190W or Less
power consumption (Standby)6W or Less
acoustic noise (Operation)52dB (A) or Less
acoustic noise (Standby)35dB (A) or Less
acoustic power6.8 Bels or Less
Operating Environment IconOperating Environment
temperature59 – 86 F° (15 – 30 C°)
relative humidity10 – 80% (No Condensation)
Weight and Dimensions IconWeight and Dimensions
printer dimensions (iPF810/iPF810 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)Approx. 768 lb. (348kg)
