Page #662 background image
Installation problems
Installation problems
The IEEE 1394 Driver Cannot Be Installed Correctly
In Windows, the device interface driver may not be installed correctly in some cases if you connected the
IEEE 1394 cable before installing the printer driver .
If so, reinstall the IEEE 1394 device interface driver and the printer driver as follows.
Important
This procedure is based on an example for Windows XP . The name of the wizard may be dif ferent
in other operating systems.
1. Right-click My Computer and choose Properties to display the System Properties window .
2. On the Hardware sheet, click Device Manager to display the Device Manager window .
3. Right-click the Other Devices icon and choose Properties .
4. On the Driver sheet, click Update Driver to start the Hardware Update W izard (or the Upgrade
Device Driver W izard ).
5. Follow the instructions on the screen.
6. When the window for choosing the source for driver installation is displayed, select the CD-ROM
drive. Insert the User Software CD-ROM provided with the printer and follow the instructions
on the screen.
The device and interface driver is installed.
The device is detected, and the New Hardware W izard (or Add New Hardware W izard )
is started.
7. Follow the instructions on the screen.
8. When the window for choosing the source for driver installation is displayed, select the printer
driver folder .
Open the CD-ROM drive, navigate to Printer_Driver > W inXP_2K > Driver , and then click OK .
(For Windows 2000/Windows XP/Windows Server 2003)
9. Follow the instructions on the screen.
The printer driver is now installed.
648 T roubleshooting

Table of Contents

Other manuals for Canon imagePROGRAF iPF810

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF810 and is the answer not in the manual?

Canon imagePROGRAF iPF810 Specifications

Print Specifications IconPrint Specifications
print resolution2400 x 1200 dpi
line accuracy±0.1% or Less
minimum line weight0.02 mm
number of nozzles (Matte Black)5, 120 Nozzles
number of nozzles (Other Colors)2, 560 Nozzles per Color
droplet size4 Picoliter
nozzle pitch (head resolution)1200 dpi x Two Rows
print-head swath1.07 inch
Ink and Media IconInk and Media
ink type (Dye)Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)Matte Black (MBK)
ink tank shipped with printerPFI-303 (330ml) MBK, C, M, Y, K
ink tank replacementPFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)10" – 44" (254mm – 1118mm)
media width (Cut Sheet)8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)59' (18m)
maximum print length (Cut Sheet)63" (1.6m)
media thickness0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter5.9" (150mm)
Power and Noise IconPower and Noise
power supplyAC 100–240V (50-60Hz)
power consumption (Maximum)190W or Less
power consumption (Standby)6W or Less
acoustic noise (Operation)52dB (A) or Less
acoustic noise (Standby)35dB (A) or Less
acoustic power6.8 Bels or Less
Operating Environment IconOperating Environment
temperature59 – 86 F° (15 – 30 C°)
relative humidity10 – 80% (No Condensation)
Weight and Dimensions IconWeight and Dimensions
printer dimensions (iPF810/iPF810 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)Approx. 768 lb. (348kg)
