Messages regarding paper
Paper cutting failed.
Cause Corrective Action
There are sheets left on the Ejection Guide .
1. Lift the Release Lever and remove the paper .
2. If Not nished printing. Finish printing
remaining jobs? is shown on the Display Screen ,
press the OK button.
Printing will resume, starting from the page on
which the error occurred.
There is a foreign object by the Output T ray ,
obstructing the Cutter Unit .
1. Lift the T op Cover and remove the foreign object.
2. If Not nished printing. Finish printing
remaining jobs? is shown on the Display Screen ,
press the OK button.
Printing will resume, starting from the page on
which the error occurred.
Y ou are not using the printer under the recommended
environmental conditions for the paper .
Use the printer only where the recommended
environmental conditions for the paper are met.
Note that various environmental conditions are
recommended for various types of paper . For details
on the recommended environmental conditions for
paper , see the Paper Reference Guide .
( → P .125)
Y ou are using paper that is not compatible with
automatic cutting.
Specify Manual as the cutting method and cut the
roll manually .
( → P .155)
For information about paper that is compatible with
automatic cutting, see the Paper Reference Guide .
( → P .125)
The Cutter Unit stops in the middle of cutting. If the Carriage is out, move the Carriage out of the
way , away from the paper .
If the Cutter is out, move the Cutter to the right side
(away from the paper) and remove the jammed paper .
( → P .147)
If the paper cannot be cut using the Cutter Unit ,
specify Manual as the roll cutting method and cut
the roll manually .
( → P .155)
In other cases, the Cutter Unit may be damaged. Contact your Canon dealer for assistance.
End of paper feed.
Cause Corrective Action
Y ou are pressing the ▲ button on the Control Panel
and trying to rewind the roll to the edge.
Release the ▲ button.
Paper can be retracted only up to 17 mm (0.7 in)
when using the Media T ake-up Unit .
Release the ▲ button.
668 Error Message

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
