Printing does not start
Printing does not start
The Data lamp on the Control Panel does not light up
Cause Corrective Action
The printer is not on. Make sure the power cord is securely plugged in, all the way . Press the
Power button to turn on the printer .
In Windows, select the printer by clicking Select Printer or Printer in
the printing dialog box and try printing again.
The printer is not selected in the
printer driver . (The printer is in
Sleep mode.)
In Mac OS X, select the printer by clicking Printer Setup Utility (or
Print Center ) and try printing again.
In Windows, restart the print job as follows.
1. Select the printer icon in the Printers and Faxes (or Printers )
window .
2. Clear Pause Printing in the File menu to restart the print job.
The print job is paused. (The
printer is in Sleep mode.)
In Mac OS X, restart the print job as follows.
1. Open the Printer Setup Utility (or the Print Center ).
2. Select the printer , and then Start Jobs in the Printers menu to
restart the print job.
The printer does not respond even if print jobs are sent
Cause Corrective Action
The printer is of ine. Press the Online button on the Control Panel to bring the printer online.
Y ou have printed when select Save
in mail box is selected in Output
Method .
Print the job saved on the printer ’ s hard disk.
( → P .519)
The display screen indicates the system is lling with ink
Cause Corrective Action
The printer was forced of f during operation. W ait until the system has been lled with ink. This
process may take about ten minutes.
T roubleshooting 629

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
