Canon imagePROGRAF iPF810 User Manual

Printer Specications
Paper ( *1 )
Rolls 254-1,1 17.6 mm (10-44 in)Paper width
Sheets 203-1,1 17.6 mm (8-44 in)
Rolls 203 ( *2 )-18,000 mm (8-708.7 in)Length of one page
Sheets 203-1,600 mm (8-63 in)
Rolls 0.07-0.8 mm (0.0028-0.031 in)Thickness
Sheets 0.07-0.8 mm (0.0028-0.031 in)
Roll width 44-in. Roll (1 1 17.6mm) , 42-in. Roll (1066.8mm) , JIS B0/B1
Roll (1030.0mm) , 36-in. Roll (914.4mm) , ISO A0/A1 Roll
(841.0mm) , 30-in. Roll (762.0mm) , JIS B1/B2 Roll (728.0mm) ,
24-in. Roll (609.6mm) , ISO A1/A2 Roll (594.0mm) , JIS B2/B3
Roll (515.0mm) , 17-in. Roll (431.8mm) , ISO A2/A3 Roll
(420.0mm) , 16-in. Roll (406.4mm) , 14-in. Roll (355.6mm) ,
ISO A3/A4 Roll (297.0mm) , 10-in. Roll (254.0mm)
Paper Size
Sheets ISO A0 , ISO A1 , ISO A2 , ISO A2+ , ISO A3 , ISO A3+ , ISO A4 ,
ISO B0 , ISO B1 , ISO B2 , ISO B3 , ISO B4 , JIS B0 , JIS B1 ,
JIS B2 , JIS B3 , JIS B4 , 34"x44" (ANSI E) , 28"x40" (ANSI
F) , 22"x34"(ANSI D) , 17"x22"(ANSI C) , 13"x19" (Super
B) , 1 1"x17" (Ledger) , Legal (8.5"x14") , Letter (8.5"x1 1") ,
36"x48" (ARCH E) , 30"x42" (ARCH E1) , 26"x38" (ARCH E2) ,
27"x39" (ARCH E3) , 24"x36" (ARCH D) , 18"x24" (ARCH C) ,
12"x18" (ARCH B) , 9"x12" (ARCH A) , DIN C0 , DIN C1 , DIN
C2 , DIN C3 , DIN C4 , 20"x24" , 18"x22" , 14"x17" , 12"x16" ,
10"x12" , 10"x15" , 8"x10" , US Photo 16"x20" , Poster
20"x30" , Poster 30"x40" , Poster 42"x60" , Poster 44"x62" ,
13"x22" , Poster 300x900mm
Normal size Printable area
• Rolls
3 mm (0.12 in) from each side
• Sheets
3 mm (0.12 in) from the top, 23 mm (0.91 in) from the bottom,
and 3mm (0.12 in) from the left and right sides
For information on the recommended print area, see “Print
Area”. (→P .105)
Print area
Borderless printing
( *3 )
Printable area (rolls)
0 mm from the top, 0 from the bottom, and 0 mm from the left
and right sides
Supported width for borderless printing 42-in. Roll (1066.8mm) , JIS B0/B1 Roll (1030.0mm) , 36-in.
Roll (914.4mm) , ISO A0/A1 Roll (841.0mm) , 24-in. Roll
(609.6mm) , ISO A1/A2 Roll (594.0mm) , JIS B2/B3 Roll
(515.0mm) , 17-in. Roll (431.8mm) , 14-in. Roll (355.6mm) ,
10-in. Roll (254.0mm)
*1: For information on the types of paper the printer supports, refer to the Paper Reference Guide .
( → P .125)
*2: When supplying paper , use a roll approximately 1,000 mm (1,093.6 yd) or longer .
*3: Printing may not be possible in some cases, depending on the type and size of paper .
102 Printer Parts

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
