Printer Driver
Setting Item Description
H Orientation Choose the printing orientation.
Making the Original Orientation Match the Paper Orientation (→P .366)
K Rotate Page 90 degrees
(Conserve Paper)
Activate this setting to rotate the document image by 90 degrees before
printing.
Conserving Roll Paper by Rotating Originals 90 Degrees (→P .345)
L Paper Source Choose the feed source, as desired.
Options displayed in the list vary depending on the selection in Media T ype
on the Main sheet.
M Roll Paper W idth Choose the roll width.
For details on available roll widths, see “Paper Sizes”. (→P .130)
N Roll Paper Options Complete optional roll paper settings. Click to display the Roll Paper
Options dialog box.
Under A Automatic Cutting , you can specify Y es or No and Print Cut
Guideline .
Cutting Roll Paper After Printing (→P .376)
Select B Banner Printing when printing multiple pages continuously .
Printing Multiple Pages Continuously (→P .320)
P Output Method Click to display the Output Method dialog box, which enables you to
complete the Output Method and Name of data to be saved settings.
O Paper Size Options
Click to display the Paper Size Options dialog box, which enables you to
register additional paper sizes or select the size system for use.
S Defaults
Restores all settings on the sheet to the default values.
408 Windows Software
