Network Setting
Conguring the IP Address on the Printer
Y ou must congure the printer ’ s IP address before using the printer in a TCP/IP network.
The printer ’ s IP address is congured automatically when you install the printer driver following the instructions
in the Quick Start Guide .
Congure the IP address by using imagePROGRAF Device Setup Utility , the printer Control Panel , or ARP or
PING commands, if the IP address is changed, or if you change the printer connection mode to a network
connection. For details on conguring the IP address, refer to the following topics.
• Conguring the IP Address Using imagePROGRAF Device Setup Utility (→P .454)
• Conguring the IP Address Using the Printer Control Panel (→P .455)
• Conguring the IP Address Using ARP and PING Commands (→P .456)
Important
• If you use a DHCP server for automatic assignment of the printer ’ s IP address, printing may no longer
be possible after the printer is turned of f and on. This is because an IP address dif ferent from before
has been assigned. Thus, when using DHCP server functions, consult your network administrator and
congure the settings in one of the following ways.
• Congure the setting for dynamic DNS updating
In RemoteUI , activate the setting Enable DNS Dynamic Update . ( → P .458)
• Congure the setting for assignment of the same IP address each time the printer starts up
Note
• W e recommend conguring the printer ’ s IP address even if you will use the printer in networks other
than TCP/IP networks. Conguring the printer ’ s IP address enables you to use RemoteUI to congure
the network settings and manage the printer with a web browser .
For details on RemoteUI , see “Using RemoteUI”. (→P .457)
Network Setting 453

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
