Canon imagePROGRAF iPF810 User Manual

Network Setting
Item Details
Default Setting
RA W Mode Bi-direction Activate this setting to use
Raw mode bidirectional
communication.
Of f
FTP Printing Activate this setting to use FTP
Printing.
On
SMTP Server Address Specify the SMTP server ’ s IP
address.
0.0.0.0
Primary DNS Server Address Specify the IP address of the
primary DNS server .
0.0.0.0
Secondary DNS Server Address Specify the IP address of the
secondary DNS server .
0.0.0.0
DNS Host Name Specify the printer host name,
up to 63 characters (1-63
characters). Use single-byte
letters, numbers, and “-”
(hyphens). Do not use numbers
or “-” for the rst character or “-”
for the last character .
NB-17FBxxxxxxxxxxxx
DNS Domain Name Specify the printer domain
name, up to 63 characters. Use
single-byte letters, numbers, “-”
(hyphens), and “.” (periods). Do
not use numbers, “-” , or “.” for the
rst character , or “-” or “.” for the
last character .
blank
Multicast DNS Service Name Specify the printer ’ s Multicast
DNS service name. (1-63
characters)
This name will be displayed when
Bonjour functions are used.
Canon iPFxxxx (xxxxxx)
7. Click OK to display the Network page.
Note
• If you specify to congure the IP address using DHCP , BOOTP , or RARP , there must be a server that
supports such protocol running in the network.
• If you specify to congure the IP address using DHCP , BOOTP , or RARP , the IP address obtained by this
method is used rst. If you cannot obtain the IP address, the address specied in IP Address is used.
• It takes a minute or two to determine whether DHCP , BOOTP , or RARP are available. W e recommend
clearing check boxes of options you will not use.
• If you are using a DNS server , select Enable DNS Dynamic Update and enter the IP Address for DNS
servers, DNS host name, and DNS domain name in Primary DNS Server Address , Secondary DNS
Server Address , DNS Host Name , and DNS Domain Name , respectively .
Network Setting 459

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
