Canon imagePROGRAF iPF810 User Manual

Adjusting the feed amount
Selecting a Feed Amount Adjustment Method (Feed
Priority)
Methods of adjusting the amount paper is fed are set for each type of paper , in the Feed Priority setting.
Adjust the Feed Priority setting to suit your particular printing application.
• Band Joint : Adjusts the feed amount to reduce banding across the sheet in printed documents.
The settings of Auto Band Adj. or Manual Band Adj are applied. If you have executed Fine Band
Adj. , in addition to the settings of Auto Band Adj. or Manual Band Adj , the settings of Fine Band
Adj. are also applied.
• Print Length : Adjusts the feed amount for better accuracy of lines in printed documents.
The settings of A:High or B:Standard/Draft in the Adjust Length menu are applied.
• Automatic : Band Joint or Print Length is selected, depending on Print Priority as selected in the
printer driver at the time of printing.
Image or Ofce Document : Band Joint is selected.
Line Drawing/T ext : Print Length is selected.
Note
• Use Manual Band Adj for transparent media or other paper for which adjustment with Auto Band
Adj. is not possible.
• Either B:Standard/Draft or A:High in the Adjust Length menu is applied, depending on printer driver
settings at the time of printing.
• If you have selected Easy Settings in the printer driver , follow these steps to conrm the Print Priority
setting.
• Windows: Click V iew Settings on the Main tab to display the V iew Settings dialog box.
• Mac OS X: Click V iew set. on the Main pane to display the V iew settings dialog box.
Follow these steps to change the Feed Priority setting.
1. Press the Menu button to display MAIN MENU .
2. Press ▲ or ▼ to select Paper Details , and then press the ► button.
3. Press ▲ or ▼ to select the type of paper , and then press the ► button.
4. Press ▲ or ▼ to select Feed Priority , and then press the ► button.
5. Press ▲ or ▼ to select Automatic , Band Joint or Print Length and then press the OK button.
Adjustments for Better Print Quality 563

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
