Canon imagePROGRAF iPF810 User Manual

Index
692 Index
Precautions when handling the Maintenance
Cartridge ...........................................................595
Replacing the Maintenance Cartridge ..............596
Replacing the Shaft Cleaner ............................600
Replacing the Printhead .........................................589
Compatible printheads .....................................589
Precautions when handling the Printhead ........589
Replacing the Printhead ...................................590
When to replace the Printhead .........................589
Resizing Originals by Entering a Scaling Value ......251
Enlarged/Reduced Printing ..............................251
Scaling ..............................................................251
Resizing Originals by Entering a Scaling Value
(Mac OS X) .............................................................254
Resizing Originals by Entering a Scaling Value
(Windows) ..............................................................252
Resizing Originals to Fit the Roll Width ..................245
Enlarged/Reduced Printing ..............................245
Fit Roll Paper Width .........................................245
Resizing Originals to Fit the Roll Width
(Mac OS X) .............................................................248
Resizing Originals to Fit the Roll Width
(Windows) ..............................................................246
Resizing Originals to Match the Paper Size ...........239
Enlarged/Reduced Printing ..............................239
Fit Paper Size ...................................................239
Resizing Originals to Match the Paper Size
(Mac OS X) .............................................................242
Resizing Originals to Match the Paper Size
(Windows) ..............................................................240
Responding to Messages .......................................657
Error Message ..................................................657
Other Messages ...............................................657
Rewinding error. .....................................................669
Roll Holder Set .................................................82, 161
Roll paper cannot be inserted into the Paper Feed
Slot .........................................................................627
Roll printing is selected, but sheets are loaded. .....664
Roll printing is selected. .........................................663
RollWdthMismatch .................................................661
S
Saved Print Jobs ....................................................492
Format of saved print jobs ................................492
Storage destination ..........................................493
Saving Print Jobs ...................................................495
Using the printer driver (Mac OS) .....................498
Using the printer driver (Windows) ...................496
Saving Print Jobs Sent from Sources Other than the
Printer Driver ..........................................................494
Specifying Output Method ................................494
Specifying Save and Print ................................494
Searching Topics ........................................................3
Selecting a Feed Amount Adjustment Method
(Feed Priority) .........................................................563
Selecting the Paper Source ............................133, 162
Selecting the Paper Type (Roll) ......................134, 232
Selecting the Paper Type (Sheet) ...................163, 233
Setting Passwords for Personal Boxes ..................503
Using imagePROGRAF Printmonitor
(Mac OS) ..........................................................507
Using imagePROGRAF Status Monitor
(Windows) ........................................................505
Using RemoteUI ...............................................503
Setting the Blue Switch on the Platen ....................639
Settings Summaries Dialog Box (Windows) ...........419
Sharing the Printer in Windows ..............................467
Sheet printing is selected. ......................................666
Sheet removed. ......................................................666
Special Settings Dialog Box (Windows) .................413
Specications ...........................................................99
Hard Disk ..........................................................103
Ink .....................................................................101
Interface ...........................................................100
Options .............................................................103
Paper ................................................................102
Printer .................................................................99
Printing performance ........................................100
Specifying Colors and Printing CAD Drawings .......198
Color Compatibility ...........................................198
Specifying Colors and Printing CAD Drawings
(Windows) ..............................................................199
Specifying NetWare Print Services .........................473
Choosing the type of print services ..................473
Using NWADMIN or PCONSOLE to set up the
print server .......................................................474
Specifying NetWare Protocols ................................476
Specifying Paper in the Printer Driver ....................234
Specifying Paper in the Printer Driver
(Mac OS X) .....................................................237, 429
Specifying Paper in the Printer Driver
(Windows) ......................................................235, 382
Specifying Printer-Related Information ...................463
Specifying the Cutting Method for Rolls .................155
Eject (waiting for ink to dry after printing) .........156
Manual (when using media that cannot be cut
using the Cutter Unit ) ......................................157

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
