Control Panel
Setting Item Description, Instructions
Smoothing
• If you choose Smooth
Line W idth Choose the width for printing lines if no width is specied in the
data. Dots in the line width are 300 dpi each.
ThickenFineLines Select On to print ne lines more distinctly .
AdjustFaintLines If ne lines are printed in colors that do not match the colors
of other shapes, selecting Off may help produce the expected
results. However , lines in some colors may appear broken.
Auto Rotate If the long side of an original is shorter than the roll width, the
original is automatically rotated 90 degrees to conserve paper .
Similarly , if the long side of an original in landscape orientation is
longer than the roll width and the short side is shorter than the
roll width, the original is repositioned to t on the paper .
HP R TL print jobs are not rotated.( *2 )
Use Nesting Selecting On will store print jobs until multiple documents can
be arranged to ll up the roll width, instead of printing each print
job as it is received.
Nesting W aitT ime Specify a time to wait until printing, as desired.
Nesting
Cut Lines Select On to print cut lines between each document on the roll.
On-the-Fly Selecting On will start printing jobs sooner if you are printing
only HP R TL print jobs and printing would not start until later .
However , images may be omitted in some cases, so be sure
to check the printing results.
*1: It is not possible to match the colors and image quality produced by the specied printer exactly .
*2: Because HP R TL images are not rotated even if the paper is rotated 90 degrees, images may be cut of f
or the blank paper may be ejected. In this case, set Auto Rotate to Off .
Printer Parts 63
To Next Page
