Cisco Catalyst 2950 Software Guide

CHAPTER
2-1
Catalyst 2950 Desktop Switch Software Configuration Guide
78-11380-03
2
Getting Started with CMS
This chapter provides these topics about the Cluster Management Suite (CMS) software:
• Features, page 2-2
• Front Panel View, page 2-4
• Topology View, page 2-10
• Menus and Toolbar, page 2-15
• Interaction Modes, page 2-25
• Wizards, page 2-26
• Online Help, page 2-27
• CMS Window Components, page 2-28
• Accessing CMS, page 2-30
• Verifying Your Changes, page 2-32
• Saving Your Changes, page 2-32
• Using Different Versions of CMS, page 2-33
• Where to Go Next, page 2-33
Note • For system requirements and for browser and Java plug-in configuration procedures, refer to the
release notes.
• For procedures for using CMS, refer to the online help.
Note This chapter describes the CMS interface of the Catalyst 2950 switches. Refer to the appropriate switch
documentation for descriptions of the web-based management software used on other Catalyst switches.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
