PurposeCommand or Action
Specifies an IPv4 address to be used as the source address
in BFD echo packets, where ip-address is the 32-bit IP
address in dotted-decimal format (A.B.C.D).
echo ipv4 source ip-address
Example:
RP/0/RP0/CPU0:router(config-bfd)# echo ipv4 source
10.10.10.1
Step 3
commit
Step 4
Specifying the Echo Packet Source Address on an Individual Interface or Bundle
To specify the echo packet source IP address on an individual BFD interface or bundle, complete the following
steps:
SUMMARY STEPS
1. configure
2. bfd
3. interface type interface-path-id
4. echo ipv4 source ip-address
5. commit
DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Enters BFD configuration mode.bfd
Example:
Step 2
RP/0/RP0/CPU0:router(config)# bfd
Enters BFD interface configuration mode for a specific
interface. In BFD interface configuration mode, you can
specify an IPv4 address on an individual interface.
interface type interface-path-id
Example:
RP/0/RP0/CPU0:router(config-bfd)# interface
gigabitEthernet 0/1/5/0
Step 3
Specifies an IPv4 address to be used as the source address
in BFD echo packets, where ip-address is the 32-bit IP
address in dotted-decimal format (A.B.C.D).
echo ipv4 source ip-address
Example:
RP/0/RP0/CPU0:router(config-bfd)# echo ipv4 source
10.10.10.1
Step 4
commit
Step 5
Routing Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
153
Implementing BFD
Specifying the Echo Packet Source Address on an Individual Interface or Bundle
