PurposeCommand or Action
To see a list of all the possible keywords and arguments
for this command, use the CLI help (?).
RP/0/RP0/CPU0:router(config-bgp-nbrgrp)#
address-family ipv4 unicast
(Optional) Applies the specified policy to inbound IPv4
unicast routes.
route-policy route-policy-name { in | out }
Example:
Step 8
RP/0/RP0/CPU0:router(config-bgp-nbrgrp-af)#
route-policy drop-as-1234 in
Exits the current configuration mode.exit
Example:
Step 9
RP/0/RP0/CPU0:router(config-bgp-nbrgrp-af)# exit
Exits the current configuration mode.exit
Example:
Step 10
RP/0/RP0/CPU0:router(config-bgp-nbrgrp)# exit
Places the router in neighbor configuration mode for BGP
routing and configures the neighbor IP address as a BGP
peer.
neighbor ip-address
Example:
RP/0/RP0/CPU0:router(config-bgp)# neighbor
172.168.40.24
Step 11
(Optional) Specifies that the BGP neighbor inherit
configuration from the specified neighbor group.
use neighbor-group group-name
Example:
Step 12
RP/0/RP0/CPU0:router(config-bgp-nbr)# use
neighbor-group nbr-grp-A
Creates a neighbor and assigns a remote autonomous
system number to it.
remote-as as-number
Example:
Step 13
RP/0/RP0/CPU0:router(config-bgp-nbr)# remote-as
2002
commit
Step 14
Configuring a Route Reflector for BGP
Perform this task to configure a route reflector for BGP.
All the neighbors configured with the route-reflector-clientcommand are members of the client group, and
the remaining iBGP peers are members of the nonclient group for the local route reflector.
Together, a route reflector and its clients form a cluster. A cluster of clients usually has a single route reflector.
In such instances, the cluster is identified by the software as the router ID of the route reflector. To increase
redundancy and avoid a single point of failure in the network, a cluster can have more than one route reflector.
Routing Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
64
Implementing BGP
Configuring a Route Reflector for BGP
