ThenIf...
The RIP packet passes authentication check at the
remote/peer end, provided the remote router is also
configured to authenticate the packets using the same
keychain.
The keychain configured on the RIP interface exists
in the keychain database ...
The RIP packet passes authentication check at the
remote/peer end, provided the remote router is also
configured to authenticate the packets using the same
keychain.
The keychain is configured with a MD5 cryptographic
algorithm...
Else, RIP packets fail authentication check.
How to Implement RIP
This section contains instructions for the following tasks:
To save configuration changes, you must commit changes when the system prompts you.
Note
Enabling RIP
This task enables RIP routing and establishes a RIP routing process.
Before you begin
Although you can configure RIP before you configure an IP address, no RIP routing occurs until at least one
IP address is configured.
SUMMARY STEPS
1. configure
2. router rip
3. neighbor ip-address
4. broadcast-for-v2
5. interface type interface-path-id
6. receive version { 1 | 2 | 1 2 }
7. send version { 1 | 2 | 1 2 }
8. commit
DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Routing Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
371
Implementing RIP
How to Implement RIP
