Using the LCD Display
Viewing System Information Using the LCD Display
Cisco Small Business NSS 322, NSS 324, and NSS 326 Smart Storage Administration Guide 190
7
STEP 10
When the login window opens , enter the adminis trator ac cou nt user na me
admin
and the new adm inistr ator pas sw ord that you created in
STEP 8
.
Viewing System Information Using the LCD Display
When the LCD display shows the NAS name and IP addres s, press the
Enter
button for two s ec ond s to enter the Main M enu. Pres s the
Select
button to move
forward through the options.
From the Main Menu you can view system information, shut down or reboot the
NAS, or modify the password for the LCD display.
The Main Menu displays the following items:
•
TCP/ IP
•
Physical Disk
•
Volume
•
System
•
Shut D own
•
Reboot
•
Password
•
Back
TCP/ IP
From the TCP/IP men u, pres s the
Select
button to move forward through the
options. In TCP/ IP, you can view the following options:
•
LAN IP Address
—IP address of this inter fac e.
•
L AN Sub net Mask
—S ubn et mask of this interfac e.
•
LAN Gateway
—IP address of the network gateway device.
•
LAN PRI. DNS
—IP address of the Domain Name System (DNS) server. This
address is typically provided by your Internet Service Provider (ISP).
