7.1.1 Data set switching 1/2
This function enables you to show the consumption data in two separate
displays. In one of the displays you can determine long-term consump-
tion periods while in the second display you can observe at the same time
shorter periods - e.g. a weld seam. You can switch between views 1 and 2
using the "Data set switching 1/2" function.
7.1.2 Seam counter Setup
In this menu you set the duration of the “Arc on” signal which is necessary
to increase the seam counter by one.
Display Messwerte Betriebsdaten
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
B E T R I E B S D A T E N
Summenzähler
Betriebszeit 12:47 Std
Verbrauchsdaten ab Reset - 1 -
Schweissnähte 0
Verbrauch
Kosten
Datensatz
umschalt
1/2
Kosten
sätze
Schweisszeit 10:17 Std
Aktuelle Naht 12.4 Sek
Schweisszeit 0.0 Sek
Draht 0.00 m
0.000 kg
Gas 0.0 l
Energie 0.000 kWh
Reset
Setup
Figure 24. "Measured values" - "Operating data" menu
Display Messwerte Betriebsdaten Setup (x.11)
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Betriebsdaten - Setup
Nahtzähler
Verzögerungszeit
0.0 sek
Figure 25. "Measured values" - "Operating data" - "Setup" menu
