MAIN (2) - Diagnostics
9.9 Config - General (3)
In this menu item you determine the minimum and maximum value that
a welding torch equipped with a potentiometer can achieve in the TIG
welding process.
10. MAIN (2) - Diagnostics
The diagnostics menu provides the following submenus:
Display Konfig Allgemein (3) ab V10
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Konfig – Allgemein (3)
Potistellbereich - WIG
Min [A] 0
Max [A] 0
Figure 51. "Config" - "General (3)" menu
Diagnose
D I A G N O S E
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Software - Versionen
System - Logbuch
Steuerung
Regelung
Leistungsteil
QWD
Kühlmodul
Roboter
Figure 52. "Diagnostics" menu
