Cloos QINEO NexT - Diagnostics - Power Unit - Mains - Measured Values; Diagnostics - Power Unit - Temperature; Diagnostics - Power Unit - Calibration

91
10.5.1.1 Diagnostics - Power unit - Mains - Measured values
This menu shows the power supply values currently measured in the weld-
ing power source.
10.5.2 Diagnostics - Power unit - Temperature
This menu shows the temperature values currently measured in the weld-
ing power source at the power unit. If the temperature is too high, an error
message appears.
10.5.3 Diagnostics - Power unit - Calibration
This menu can only be used by authorised service personnel.
Diagnose – Messwerte
Netzspannung L1/L2 4.8 V
Netzspannung L2/L3 5.0 V
Netzspannung L3/L1 5.0 V
Netzfrequenz 0.00 Hz
Phase L1/2-L2/3 0 Grad
Phase L2/3-L3/1 0 Grad
Diagnose – Messwerte
Figure 71. "Diagnostics" - "Power unit" - "Mains" - "Measured values" menu
Diagnose – Temperaturen
Zuluft 25 °C
Abluft 26 °C
Trafo 27 °C
Primär 26 °C
Sekundär 28 °C
AC-Rechts 25 °C
AC-Links 28 °C
AC-Abluft 29 °C
Diagnose – Temperaturen
Figure 72. "Diagnostics" - "Power unit"- "Temperature" menu
Diagnose – Abgleich
Diagnose – Abgleich
Abgleich
Speichern
Strom 0.0 A
Verstärkung 1.0000
Nullpunkt 0.00
Spannung 0.15 V
Verstärkung 1.0000
Nullpunkt 0.00
Sense-Spannung -0.06 V
Verstärkung 1.0000
Nullpunkt 0.00
Figure 73. "Diagnostics" - "Power unit"- "Calibration" menu
