Cloos QINEO NexT - Config - General - QWD - QWD-B

65
Wire end control
Use this menu to select the signal transmitter for the wire end control of
the respective wire feed distance.
Function Description
Automatic*
1
Welding power source recognises the devices
connected and automatically selects the wire drive
unit nearest to the wire storage to be the signal
transmitter.
QWD contact sen-
sor / ring sensor*
2
Welding power source waits for the selected sensor
signal from QWD-A.
QWDBx_1 contact
sensor / ring
sensor*
2
Welding power source waits for the selected sensor
signal from QWD-B.
QWDBx_2 contact
sensor / ring
sensor*
2
Welding power source waits for the selected sensor
signal from an additional QWD-B "x_2" connected
in series with a QWD-B "x_1".
9.1.7.1 Config - General - QWD - QWD-B
The maximum value for the "Threading" function is configured in this
menu, refer to Figure 34.
During threading the wire feed speed is continuously increased. In a period
of 20 seconds it increases from 0m/min to the maximum value.
Figure 33. "Config" - "General" - "QWD" menu
Display Konfig – Allgemein – QWD
ab V3.31 NexT
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Draht von Hand
Konfiguration Sollwert
QWD
Push-Pull
Konfig - QWD
Drahtende-Sensorik für Drahtstrecke
1 Automatik
2 Automatik
3 Automatik
4 Automatik
QWD-B
Sollwert 10,0 m/min
Einfädeln
Konfiguration Sollwert
Sollwert 10,0 m/min
*
1
Applicable if the wire drives
involved are equipped with a key
switch or with a pre-assembled
jumper for selecting the signal
transmitter for wire monitoring.
*
2
Required if configuration by
means of a key switch or pre-as-
sembled jumper is not possible.
Figure 34. "Config" - "General" - "QWD" - "QWD-B" menu
Display Konfig – Allgemein – QWD – QWD-B
ab V3.31 NexT
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Konfig – QWD-B
Typ QN WD B1.1
Einfädelgeschwindigkeit 6.0 m/min
