96
MAIN (2) - Diagnostics
10.6.2 Diagnostics - Wire drive unit - QWD-MD / QWD-A
A QWD-MD is a QWD-A specially adapted for the MoTion process. This
menu shows the components identified and the following parameters:
• "Wire set value" specifies the value received by the wire drive unit
during certain functions, such as "Thread", "Inching-in", "Upslope",
"Downslope" and "Wire by hand".
• "Push-Pull" is not relevant.
• "Sensor wire buffer" is the sensor value of the MCU. The value range is 0
to 1000 and represents the position of the wire within the MCU. Values
between 200 and 800 are in the standard.
Valves Buttons Options
This menu displays current signal states and additional options that might
be enabled. If the signal state is 1 (On), the corresponding box is highlight-
ed in yellow.
This menu is also displayed as a submenu for the QWD-A.
Ventile
Tasten
Optionen
Diagnose - QWD
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Drahtantriebstyp QWD-MD
Software-Version 02.11.87
Motortyp DC Big
Antriebseinheit QN WF22
Zusatzantrieb MD
Draht Sollwert 0.0 m/min
Push-Pull 0
Sensor Drahtpuffer 0
Diagnose Drahtantriebe QWD v3.x.x
Figure 82. "Diagnostics" - "Wire drive unit" - "QWD-MD" menu
INFO!
Diagnose Drahtantriebe QWD v3.x.x
Diagnose - QWD
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Optionen
Ventile Tasten
Drahtfühler
Ringsensor
Gas
Luft
Brenner
Draht –Z
Draht
Gas
Gasdruckschalter
QWD-Schwinge 0.0 m/min
CDD -Schwinge
Gasdruchflußsensor 0.0 l/min
Figure 83. "Diagnostics" - "Wire drive unit" - "QWD-MD" - "Valves Buttons Options" menu
