10.5 Diagnostics - Power unit
This menu contains status information of modules connected to the power
unit.
Software version corresponds to PCU software, see "Diagnostics" --> "Soft-
ware version" "Modules:" "QN PCU".
10.5.1 Diagnostics - Power unit - Mains
This menu shows the values currently measured in the welding power
source of the connected mains supply.
Diagnose – Leistungsteil
Inverter
Stromnetz
Abgleich
Temperatur
Lüfter
Led
Typ: Inverter DC
Leistung: 450 A
Software-Version: 01.03.00
PLD-Version: 01.10.61
Treibertyp: 1
Diagnose – Leistungsteil V.01.03.xx
Figure 69. "Diagnostics" - "Power unit" menu
Diagnose – Netz
Messwerte
Frequenz synchronisiert
Frequenzbereich
Phasenlage unbekannt
Zwischenkreisfreigabe – Int.
Zwischenkreisfreigabe – Ext.
Zwischenkreis – Status
Diagnose – Netz
Figure 70. "Diagnostics" - "Power unit" - "Mains" menu
