7.1.3 Consumption costs
This function shows the costs for the number of weld seams, wire, gas and
energy.
The cost analysis is started by means of the "Reset" function or is reset to 0.
8. MAIN - Display
This function enables switching between different display versions.
Version 1
In addition to the reference variable "Wire speed", the parameters "Sheet
thickness", "Aset" and "Vset" are displayed. In addition, the parameters
"ArcLength" and "ArcDynamic" are shown, see Figure 27.
Display Messwerte Verbrauchskosten (x.11)
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
B E T R I E B S D A T E N
Summenzähler
Betriebszeit 12:47 Std
Kosten ab Reset - 1 -
Schweissnähte 0
Verbrauch
Kosten
Datensatz
umschalt
1/2
Kosten
sätze
Schweisszeit 10:17 Std
Aktuelle Naht 12.4 Sek
Draht 0.00 Euro
Energie 0.00 Euro
Reset
Gas 0.00 Euro
Setup
Figure 26. "Measured values" - "Operating data" - "Consumption costs" menu
Menü1 Anzeige v1.3.xx
Synergie
Betriebs
-
art
Verfahren
Funktion
M A I N
Program-
mieren
Messwerte
Anzeige

Puls 4 -Takt
Dyn.
8.5 m / min
-2
4
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
C - Start
Blechdicke 8.5 mm
ASet 230 A
VSet 27.9 V
1
Figure 27. Display variant 1
