MAIN (2) - Diagnostics
10.3.4 Diagnostics - Control - LED
In this menu you test the functionality of the LED of the control. The
controller is normally fitted in the welding power source and so no LED is
connected. If the controller is connected as an external module, test the
functionality of the LED by moving the middle rotary knob to mode "Diag-
nostics".
The parameters can now be changed. The LED adapts to the changed
values.
Diagnose - Led
Diagnose Led
Mode
Frequenz 0.1 Hz
Tastverhältnis 100 %
Rot 10 %
Grün 0 %
Blau 0 %
Diagnose
Figure 61. "Diagnostics" - "Control"- "LED" Diagnostics mode active menu
Diagnose - Led
Diagnose Led
Mode
Frequenz 0.1 Hz
Tastverhältnis 100 %
Rot 10 %
Grün 0 %
Blau 0 %
Diagnose
0.1 Hz
Figure 62. "Diagnostics" - "Control"- "LED" Edit LED status menu
