9.8 Config - General (2)
Wire feed display
Under this menu item you can select the dimension display for the wire
speed.
Job continuation
The job continuation can be applied in the 4-cycle and Super-4-cycle
operating modes. If job continuation is active in Super-4-cycle, this has
priority over the "Step modulation" function.
Up to 10 jobs can be toggled with the torch trigger of any manual weld-
ing torch. Press and hold the torch trigger for approximately 0.5 seconds
to start a job continuation.
The start job must be in the first position of any tens position, for exam-
ple: Storage space 11, 21, 31 … 801. As soon as an empty storage space is
available between an active job and the next job, this is detected and the
system will jump back to the job with the position xx1.
Example:
Active job: 44, next job: 48, job continuation to storage space: 41.
Terminal/process voltage
Select whether the display shows the process voltage (terminal voltage
minus values of the external welding current circuit = calculated voltage
at the workpiece) or the terminal voltage (voltage at the welding power
source).
Limit values gas-yes-signal
Determine the minimum and maximum limit values for the "Gas-Yes-
Signal" in litres.
Display Konfig Allgemein (2) ab V2 NexT
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Konfig – Allgemein (2)
Drahtvorschub - Anzeige
Drahtvorschub in m/min
Klemmen-/Prozessspannung
Display zeigt
Prozessspannung
Grenzwerte Gas-Ja Signal
Min [l] 8.0
Max [l] 30.0
Job - Fortschaltung
Fortschaltung Aus
Figure 50. "Config" - "General (2)" menu
