MAIN (2) - Config (Configuration)
9.1.6 Config - General - Sense technology
This section only applies to welding power sources type:
• QINEO NexT Premium
In order to monitor the welding process, the terminal voltage is measured
on the welding power source and the voltage is measured close to the
welding process (torch).
These Sense lines have an immediate effect on the regulator settings of the
welding process. Thus, the sense technology supervises a differential volt-
age between the torch and the connections on the welding power source.
This function is only active during the Control Weld process!
If the differential voltage exceeds a certain value, e. g. interruption of the
external welding current circuit, this would result in not controllable pa-
rameter settings.
If a defined differential voltage is exceeded, the system - for safety reasons
- immediately switches over to the terminal voltage of the welding power
source in order to prevent uncontrollable parameter settings.
Sense technology On/Off
Mode: On or Off
Sense technology Differential voltage
Difference: 0.0 V…40.0 V
If the adjusted voltage is exceeded, the error message "Err. 25 Sense voltage
exceeded!" appears on the display.
9.1.7 Config - General - QWD
The wire speed for the "Wire forward" and "Threading" functions is config-
ured in this menu, refer to Figure 33.
Wire by hand
Configuration "from Job"
The value saved in the job specifies the speed for the "Wire forward"
function.
Configuration "Set value"
The value specifies the speed for the "Wire forward" function.
Threading (only in connection with MoTion Equipment)
Configuration "from Job"
When the "Threading" function is activated, the value saved in the job
specifies the speed for the "Wire forward" function, refer to chapter 5.4
on page 44.
Configuration "Set value"
When the "Threading" function is activated, the value specifies the speed
for the "Wire forward" function, refer to chapter 5.4 on page 44.
Konfig Allgemein Konfig - Sensetechnik
Puls 4 -Takt
V
0
A
1.2 mm Fe
82% Argon 18% Co
2
0.0
Konfig - Sensetechnik
Sensetechnik Differenzspannung
Ein
Differenz
Sensetechnik Ein/Aus
Modus
10.0V
Figure 32. "Config" - "General" - "Sense technology" menu
