List of ADU events
99-145912-A Appendix C: System messages C-3
System messages
0A018-0 Antenna ERROR ISM ABS device Cannot initialise the ISM Info:
0x00000000: Device not found (possible
cabling problem)
0x000cbbaa: Device internal error (replace
device) aa=status, bb=state, c=calibration data
error.
0A019-0 Antenna ERROR PMM ABS device Cannot initialise the PMM. Info: See 0A015-0.
0A01A-0 Antenna ERROR BCM ABS device Cannot initialise the BCM. Info: See 0A015-0.
0A01E-0 Antenna ERROR Sensor sanity Too many invalid values measured by the ISM
during initialisation. Check for vibrations or
malfunctioning ISM.
0A021-0 Antenna ERROR Azi axis calibration Azimuth axis zero reference not found. Check
belt and zero reference module. Info:
0x00000001: Timeout (operation did not
complete in time)
0x00000010: Encoder or mechanical problem
0x00000020: Zero reference not found
0x00000040: End stop not found.
0A022-0 Antenna ERROR Xel axis calibration Cross-elevation axis zero reference or end stops
not found at expected locations. Check belt,
zero reference module, and end stops. Info: See
0A021-0.
0A023-0 Antenna ERROR Ele axis calibration Elevation axis zero reference or end stops not
found at expected locations. Check belt, zero
reference module, and end stops. Info: See
0A021-0.
0A025-0 Antenna ERROR Antenna
calibration
One or more errors occurred during antenna
start-up Info:
0x00000001: Timeout (calibration did not
complete in time)
0x00000010: Azimuth axis
0x00000020: Cross-elevation axis
0x00000040: Elevation axis
0x00000080: Polarisation axis
0A028-0 Antenna ERROR Demodulator load The second receiver demodulator cannot be
initialised and loaded correctly.
0A029-0 Antenna ERROR XIM PLL lock The PLL on the VIM/TIM does not lock.
Error
code
(ID)
Unit Severity Description Explanation
Table C-1: ADU event messages (Continued)
