C-4 Appendix C: System messages 99-145912-A
0A02B-0 Antenna ERROR ABS software
version
The ABS software version in the antenna is too
old to match the hardware requirements.
Upgrade the software.
0A02D-0 Antenna ERROR BUC reference
switch
The BUC reference switches do not work. Check
PCM-VIM cable and replace cable, VIM or PCM.
0A034-0 Antenna WARNING ACU
communication
The communication link between ACU and
antenna is down.
0A035-0 Antenna WARNING ISM data valid Sensor measurements from the ISM are invalid.
This indicates a malfunctioning ISM.
0A036-0 Antenna WARNING ISM data range Sensor measurements from the ISM are out of
range.
0A037-0 Antenna WARNING GNSS
communication
Lost connection to the GNSS device.
0A038-0 Antenna WARNING GNSS data range Received information from the GNSS device
which is out of range.
0A039-0 Antenna WARNING GNSS device
warning
Local GNSS device warning.
0A03A-0 Antenna WARNING GNSS device error Local GNSS device error.
0A03B-0 Antenna ERROR Azi DDM shutdown The azimuth motor control has detected one of
the following situations: Extreme temperature,
voltage, current or velocity. The motor was then
shut down. This is usually a temporary situation
and is probably fixed by a restart of the system.
0A03C-0 Antenna ERROR Xel DDM shutdown As Azi DDM shutdown but detected by the
cross-elevation motor control.
0A03D-0 Antenna ERROR Ele DDM shutdown As Azi DDM shutdown but detected by the
elevation motor control.
0A03E-0 Antenna ERROR PMM shutdown As Azi DDM shutdown but detected by the
polarisation motor control.
0A03F-0 Antenna WARNING AMB timing This indicates a busy situation. It may occur
during installation procedures. No user
interaction is required.
0A040-0 Antenna WARNING VIM cable attn The output power cannot be controlled
correctly. Check the Tx chain.
Error
code
(ID)
Unit Severity Description Explanation
Table C-1: ADU event messages (Continued)
