COBHAM SAILOR 100 GX User Manual

Configuration with the web interface
6-20 Chapter 6: Configuration 99-145912-A
VSAT MODEM Description
Model VSAT modem name, entered in SETTINGS > VSAT modem
profiles.
RX locked status Demodulator lock of the GMU.
RX IF frequency Read out from the GMU.
TX allowed Yes or no. Indicates if the GMU supplies the 50 MHz reference signal
on its TX connector (On) and if an iDirect OpenAMIP modem
indicates modem Locked and Tx ON in the OpenAMIP message L (L
1 1).
Table 6-8: Web interface, DASHBOARD, VSAT MODEM section
POINTING Description
Azimuth relative Current value for azimuth, relative to the vessel heading.
Elevation relative Current value for elevation, relative to the vessel.
Polarisation skew Current value for polarisation skew.
Table 6-9: Web interface, DASHBOARD, POINTING section
TX Description
BUC TX On or Off. Shows if the SAILOR 100 GX has enabled the BUC or not.
It is the same TX ON/TX OFF as shown in the display of the ACU, see
ACU display and keypad on page 6-39.
Table 6-10: Web interface, DASHBOARD, TX section
