COBHAM SAILOR 100 GX User Manual

Configuration with the web interface
99-145912-A Chapter 6: Configuration 6-29
Configuration
The following parameters are recorded in the statistics report:
Parameter recorded Description
Host name Host name, entered in the web interface on the
page SETTINGS > Network.
ACU SN ACU serial number
ADU SN ADU serial number
SW ver. Software version
System type SAILOR 100 GX
Table 6-12: Statistics report, header record
Parameter recorded Description
UTC. (s)
UTC (YYYY-MM-DD hh:mm)
UTC in seconds and date format for the data set.
RSSI.Av
RSSI.Max
RSSI.Min
Received signal strength (average, maximum and
minimum value) for the sampling interval.
POS.Lat (degree)
POS.Long (degree)
POS.Valid
Latitude value of position.
Longitude value of position.
Fix = valid position, No Fix = invalid position.
Heading.Samp (degree)
Heading.Max (degree)
Heading.Min (degree)
Heading.Range (+/-degree)
Ship’s heading (sample, maximum and minimum
value, range) for the sampling interval. See Figure 6-
21: Statistics — how to read data for a range.
Antenna.Azi (degree)
Antenna.Azi Max (degree)
Antenna.Azi Min (degree)
Antenna.Azi Range (+/-degree)
Current antenna azimuth (sample, maximum and
minimum value, range) for the sampling interval. See
Figure 6-21: Statistics — how to read data for a
range.
Antenna.Ele (+/-degree)
Antenna.Ele Max (+/-degree)
Antenna.Ele Min (+/-degree)
Current antenna elevation (sample, maximum and
minimum value) for the sampling interval.
Vsat.rx_lo_freq (GHz)
Vsat.tx_lo_freq (GHz)
Rx LO frequency of modem for this record.
Tx LO frequency of modem for this record.
Tracking.rf freq (GHz)
Tracking.type
Tracking RF frequency for this record.
Narrow filter, DVB-S2 decoder and modem RSSI and
GSC.
Sat.long (degree) Longitude position of the satellite.
Table 6-13: Parameters recorded in a statistics report
