HF SSB transceiver reference manual 11-9
Ancillary
equipment
Transceiver rear panel
connection
Notes
8571 Remote control
interface
Remote Control
connector
9300 ALE controller GP connector Set RS-232 setting to
9300
ALE
and baud rate to
9600
.
9366 or 9330
control head
Remote Control
connector
Automatic antenna
and antenna tuners
Antenna Control
connector
Computer RS-232 socket Set RS-232 setting to
COMPUTER
and baud rate to
the value used by the computer
(typically
9600
).
Data and fax
modems
GP connector
Extension
loudspeaker
L/S socket
External alarm Ext Alarm socket
GPS receiver RS-232 socket Set RS-232 setting to
GPS
NMEA-0183
and baud rate to
the value used by the GPS
receiver (typically
4800
).
IPC-500 telephone
interconnect
Remote Control
connector

Appendix
HF SSB transceiver reference manual 11-9
Ancillary
equipment
Transceiver rear panel
connection
Notes
8571 Remote control
interface
Remote Control
connector
9300 ALE controller GP connector Set RS-232 setting to
9300
ALE
and baud rate to
9600
.
9366 or 9330
control head
Remote Control
connector
Automatic antenna
and antenna tuners
Antenna Control
connector
Computer RS-232 socket Set RS-232 setting to
COMPUTER
and baud rate to
the value used by the computer
(typically
9600
).
Data and fax
modems
GP connector
Extension
loudspeaker
L/S socket
External alarm Ext Alarm socket
GPS receiver RS-232 socket Set RS-232 setting to
GPS
NMEA-0183
and baud rate to
the value used by the GPS
receiver (typically
4800
).
IPC-500 telephone
interconnect
Remote Control
connector

