Codan HF SSB User Manual

Appendix
11-14 HF SSB transceiver reference manual
Specifications
Channel capacity Refer to the front of the HF SSB transceiver user guide.
Frequency range Refer to the front of the HF SSB transceiver user guide.
Operating mode Refer to the front of the HF SSB transceiver user guide.
Transmitted power Refer to the front of the HF SSB transceiver user guide.
Supply voltage 12V DC nominal, negative earth
Normal operating range 10.5V to 15V DC
Maximum operating range 9V to 16V DC
Reverse polarity protection provided
Overvoltage
protection
Shutdown at 16V DC (nominal) for duration of overvoltage
Supply current Receive (no signal): 0.75A
Transmit J3E voice: 6A (average)
J3E two tone: 9–12A
Size and weight HF SSB transceiver (excluding vehicle mounting frame)
Dimensions: 250mm W x 320mm D x 78mm H
Weight: 3.3kg
9366 or 9330 control head (including mounting bracket)
Dimensions: 140mm W x 40mm D x 80mm H
Weight: 0.4kg

Appendix
11-14 HF SSB transceiver reference manual
Specifications
Channel capacity Refer to the front of the HF SSB transceiver user guide.
Frequency range Refer to the front of the HF SSB transceiver user guide.
Operating mode Refer to the front of the HF SSB transceiver user guide.
Transmitted power Refer to the front of the HF SSB transceiver user guide.
Supply voltage 12V DC nominal, negative earth
Normal operating range 10.5V to 15V DC
Maximum operating range 9V to 16V DC
Reverse polarity protection provided
Overvoltage
protection
Shutdown at 16V DC (nominal) for duration of overvoltage
Supply current Receive (no signal): 0.75A
Transmit J3E voice: 6A (average)
J3E two tone: 9–12A
Size and weight HF SSB transceiver (excluding vehicle mounting frame)
Dimensions: 250mm W x 320mm D x 78mm H
Weight: 3.3kg
9366 or 9330 control head (including mounting bracket)
Dimensions: 140mm W x 40mm D x 80mm H
Weight: 0.4kg

