Codan HF SSB User Manual

Link Setup mode
HF SSB transceiver reference manual 9-5
Antenna band or channel control
This procedure is used to control the output of switching
signals at the
Antenna Control
connector on the back
panel of the transceiver.
You only need to use this procedure if you are using the
transceiver to control equipment such as a multiple antenna
installation or a switchable multi-frequency antenna. If you
are using an automatic tuning antenna, any settings made by
this procedure are ignored.
You can select:
•
CHANNEL
if you want the transceiver to control
equipment according to the single frequency of the
current channel
•
BAND SET 1
or
BAND SET 2
if you want the
transceiver to control equipment according to the
operating frequency band of the supporting equipment
(for example, add-on high power linear amplifiers).
The following table provides the switching frequencies for
the outputs. For further details, contact your Codan agent.
Outputs
421
Bandset 1
frequency ranges
(MHz)
Bandset 2
frequency ranges
(MHz)
LLL < 2
L L H 2–2.99999 < 2
L H L 3–3.99999 2–2.99999
L H H 4–5.99999 3–4.99999
H L L 6–8.99999 5–7.99999
H L H 9–12.99999 8–12.99999
H H L 13–19.99999 13–19.99999
H H H 20–30 20–30
Link Setup mode
HF SSB transceiver reference manual 9-5
Antenna band or channel control
This procedure is used to control the output of switching
signals at the
Antenna Control
connector on the back
panel of the transceiver.
You only need to use this procedure if you are using the
transceiver to control equipment such as a multiple antenna
installation or a switchable multi-frequency antenna. If you
are using an automatic tuning antenna, any settings made by
this procedure are ignored.
You can select:
•
CHANNEL
if you want the transceiver to control
equipment according to the single frequency of the
current channel
•
BAND SET 1
or
BAND SET 2
if you want the
transceiver to control equipment according to the
operating frequency band of the supporting equipment
(for example, add-on high power linear amplifiers).
The following table provides the switching frequencies for
the outputs. For further details, contact your Codan agent.
Outputs
421
Bandset 1
frequency ranges
(MHz)
Bandset 2
frequency ranges
(MHz)
LLL < 2
L L H 2–2.99999 < 2
L H L 3–3.99999 2–2.99999
L H H 4–5.99999 3–4.99999
H L L 6–8.99999 5–7.99999
H L H 9–12.99999 8–12.99999
H H L 13–19.99999 13–19.99999
H H H 20–30 20–30
