InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 106
AMF26-P-2.4 Reference Guide.pdf
Cummins engines with MODBUS communication
IL-NT set up:
Basic settings:COM1 Mode = ECU LINK or COM2 Mode = ECU LINK
Software configuration: ECU → ECU engine is connected → Type: Cummins MODBUS
RS232/RS485 converter (see following diagram) set up:
Data format settings (SW1) 11 bits (1 start bit, 8 data bits, 2 stop bits)
Baud rate settings (SW2) 9600 bps
(more info available on http://www.advantech.com/products/Model_Detail.asp?model_id=1-D6FLH)
