Timer is activated on selected day interval.
12 Hours/8 Hours/6 Hours/4 Hours/3 Hours/2 Hours/1 Hour:
Timer is activated at midnight for TimerXDuration time. Then is activated again after period chosen for
TimerX Repeat parameter. This cycle will be repeated with the same period.
Example:
For instance when Timer1 Repeat = 6 hours and Timer1Duration = 180 minutes then Timer1 Function
is activated periodically every 6 hours starting at midnight and running every time for 180 minutes (3
hours). So Timer is active from midnight to 3 am, then from 6 am to 9 am, then from noon to 3 pm,
then from 6 pm to 9 pm and then the whole cycle starts again at midnight.
Hint:
There is an exception in case that TimerXDuration is higher then TimerX Repeat. In this case Timer is
started again in next full cycle. For instance when you set Timer2 Repeat = 2 hours and
Timer2Duration = 180 minutes Timer2 will be activated at midnight for 3 hours and then again at 4 am
again for 3 hours, then next cycles would follow.
Timer1..3 ON Time
Day time when Timer output activates.
Timer1..3Duration
Specify length of Timer activation.
Step: 1 min
Range: 1 – 1440 s
Sensors Spec
AI1,AI2,AI3Calibration […]
Calibrating constant to adjust the measured value of IL analog inputs. Physical dimension
of calibrating constant is corresponding to Analog input.
Step: 1
Range: -1000 – +1000
Hint:
Calibration constants have to be adjusted when measured value is near the alarm level
User curves can be defined by LiteEdit software.
Extension I/O
IOM AI1..4 Wrn [ ]
The warning level for IOM ANALOG INPUT 1..4 alarm detection.
Step: 1
Range: -100 – +10000
IOM AI1..4 Sd [ ]
The shutdown level for IOM ANALOG INPUT 1..4 alarm detection.
Step: 1
Range: -100 – +10000
IOM AI1..4 Del [s]
Delay for IOM ANALOG INPUT 1..4 alarm.
Step: 1 s
Range: 0 – 900 s
