InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 68
AMF26-P-2.4 Reference Guide.pdf
Setpoints
Password
EnterPassword
Password is a four-digit number. Password enables change of relevant protected setpoints.
Use n or p keys to set and ENTER key to enter the password.
Hint:
There is only 1 level of a password.
ChangePassword
Use n or p keys to set and ENTER key to change the password.
Hint:
At first the password has to be entered before the new password can be changed.
Password is usually required during configuration of controller or for adjustment of password protected
setpoints (the ones marked with asterisk when password not entered). Default controller password is
“0”. Maximum value of password is “9999”.
Basic Settings
Gen-set Name
User defined name, used for IL-NT identification at remote phone or mobile connection.
Gen-set Name is max 14 characters long and have to be entered using LiteEdit software.
Nominal Power [kW]
Nominal power of the generator
Step: 1kW
Range: 1 – 5000 kW
Nomin Current [A]
It is current limit for generator IDMT over current and short current protection and means maximal
continuous generator current. See Gener Protect: Amps IDMT Del, GShortCrct Sd setpoints.
Nominal Current can be different from generator rated current value.
Step: 1 A
Range: 1 - 10000 A
CT Ratio [/5A]
Gen-set phases current transformers ratio.
Step: 1 A
Range: 1 – 5000 A / 5A
Hint:
For firmware IL-NT-Pramac-1.0, 1.1, 1.2 and IL-NT-AMF26P-1.0:
For CT Ratio <= 250 the values of power and current are displayed in a controller with one decimal.
For CT Ratio > 250 the values of power and current are displayed in a controller with integral
numbers. If you change CT Ratio in LiteEdit or directly in the controller, decimal numbers will not be
changed immediately. The change will be executed only by reconfiguring in LiteEdit. The statistics of
power will be recounted at this time with regards to decimal numbers of power.
WARNING! When you change the firmware, statistics can be invalid!
WARNING! Change of CT ratio over value 250 without reconfiguring in LiteEdit can cause
overflow of current measurement and improper function of controller!
