InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 71
AMF26-P-2.4 Reference Guide.pdf
Three phase “delta” measurement – 3PD
Split Phase: DOUBLE DELTA Connection, Split Phase,
Single-phase measurement – 1PH
Mono Phase: MONOPHASE,
Single-phase measurement – 1PH
Hint:
For more details about connection types see Voltage measurement and generator connection types.
CT Location [Load / GenSet]
Load: CT (current measurement) is located next to the load.
GenSet: CT (current measurement) is located next to the gen-set.
For more details about current measurement location see Current measurement: CT location.
Number Of CTs [3CTs / 1CT]
3CTs:
It means that there are 3 CTs used for current measurement. This is valid in case of 3Ph4Wire or
3Ph3Wire connection type. This setting should be also used in case of Split Phase connection type,
when there are just 2 CTs (as there are just two phases). This setting doesn’t make sense in case of
Mono Phase connection type (Even though you can use this setting in case of Mono Phase, but the
result is the same as for 1CT).
1CT:
When 1CT is used for current measurement.
For more details about CT connection see Current measurement: Number of CTs = 3CTs/1CT .
CB Feedbacks [ENABLED, DISABLED]
When ENABLED (default setting) and MCB and/or GCB configured, the feedback/s are evaluated.
When DISABLED then even when MCB and/or GCB configured they are not evaluated.
Comms Settings
ControllerAddr (1 .. 32) [-]
Controller identification number. It is possible to set controller address different from the default value
(1) so that more IL controllers can be interconnected (via RS485) and accessed e.g. from Modbus
terminal.
Hint:
When opening connection to the controller it's address has to correspond with the setting in PC tool.
From LiteEdit it is only possible to connect to controllers with address 1.
COM1 Mode [DIRECT/MODEM/MODBUS/ECU LINK]
Communication protocol switch for the COM1 channel.
DIRECT: LiteEdit communication protocol via direct cable.
MODEM: LiteEdit communication protocol via modem.
MODBUS: Modbus protocol. See detailed description in InteliCommunication guide.
ECU LINK: Protocol for communication with Cummins engines via Modbus.
Hint:
