ComAp InteliLite NT AMF26-P - Technical Data; Inputs;Outputs Overview; Generator Protections

InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 160
AMF26-P-2.4 Reference Guide.pdf
Technical Data
Inputs/Outputs overview
Model
BIN
BOUT
AI
COM1
COM2
CAN
RPM
Gen.
Voltage
Mains
Voltage
Gen.
Current
IL-NT-AMF26-P
7+1/7*
7+2/7*
3
Y**
Y**
Y
Y
Y
Y
Y
* With optional IL-NT-EFCPM/IL-NT-EFCPM2 module
** With optional communication plug-in module
Y -Available
N -Not available
Generator protections
ComAp gen-set controllers provide following range of generator protections.
For each protection adjustable limit and time delay are available.
Comparison table with ANSI codes:
ANSI
code
Protection
IL-NT
AMF26P
59
Overvoltage
•
27
Undervoltage
•
47
Voltage Assymetry
•
81H
Overfrequency
•
81L
Underfrequency
•
50+51
Overcurrent
•
46
Current Unbalance
•
32
Overload
•
51N+64
Earth Fault
-
32R
Reverse Power
-
25
Synchronism Check
-
47
Phase Rotation
**
37
Undercurrent
-
55
Power Factor
-
71
Gas (Fuel) Level
•
Note:
-
Not available
•
Available
**
Fixed setting
