InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 165
AMF26-P-2.4 Reference Guide.pdf
IL-NT S-USB interface (optional card)
Plugs into IL-NT controller COMMUNICATION MODULE port.
Maximal distance 5m
Maximum Speed Up to 57,6 kBd (DIRECT), 38,4kBd Analog
modem, 9,6 kBd digital modem, 57,6 kBd (MODBUS)
Use only shielded A-B USB cables up to 5m length.
Recommend USB cable:
USB-LINK CABLE 1.8M – ComAp A-B USB cable.
Hint:
With SW version IL-NT 1.2 and older, the communication speeds are 19,2kBd (STD/DIRECT),
19,2kBd Analog modem, 9,6 kBd digital modem, 9,6kBd (MODBUS)
IL-NT-AOUT8 interface (optional card)
Plugs into IL-NT controller EXTENSION MODULE port.
Number of PWM outputs 8
PWM frequency 250Hz
Maximum current 0,5 A
Maximum switching voltage 36 VDC
Output resistance 1Ω
Resolution 10 bits
IL-NT-EFCPM interface (optional card)
Dimension (WxHxD) 66x37x10 mm (2,6’x1,45’x0,4’)
Weight 124g
Interface to controller Direct mounted
Earth fault current protection input Not galvanic separated
Input range up to 8,32 mA
Binary Input Not galvanic separated
Input resistance – 4,2kohm
Input range – 0 VDC to 36 VDC
Binary outputs (open collector) Not galvanic separated
Maximum current – 1,0 ADC
Maximum switching voltage – 36 VDC
Voltage drop 1 VDC
Storage temperature - 40°C to + 80°C
Operating temperature - 40°C to + 70°C
IL-NT-EFCPM2 interface (optional card)
Plugs into IL-NT controller EXTENSION MODULE port. It contains 1 current input dedicated for earth
fault current protection and 7 dedicated pins which can be configured as binary inputs or outputs.
Dimension (WxHxD) 66x37x10 mm (2,6’x1,45’x0,4’)
Weight 124g
Interface to controller Direct mounted
Storage temperature - 40°C to + 80°C
Operating temperature - 40°C to + 70°C
