Dummy Load function is primarily dedicated to secure healthy gen-set running in case gen-set load is
not sufficient (is too low). There are 2 independent parameters for two independent Dummy Load
levels. Using opposite logic, Dummy Load function can be also used for Load Shedding purpose. It
only depends on Dummy Ld ON and OFF values. When ON value is higher than OFF value, then the
function can be used for Load Shedding, when lower then fro Dummy Load. See the logic in pictures
below.
Engine Protect
ProtectHoldOff [s]
During the start of the gen-set, some engine protections have to be blocked (e.g. Oil pressure).
The protections are unblocked after the ProtectHoldOff time. The time starts after reaching Starting
RPM.
Step: 1s
Range: 0 – 300 s
Horn Timeout [s]
Max time limit of horn sounding. Set to zero if you want to leave the output HORN open. Horn timeout
starts again from the beginning if a new alarm appears before previous Horn timeout has elapsed.
Step: 1s
Range: 0 – 600 s
Overspeed [%]
Threshold for over speed protection
