InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 86
AMF26-P-2.4 Reference Guide.pdf
AMF Settings
Operation Mode [AMF/MRS/SLAVE/MASTER]
Based on this setpoint is defined basic controller function.
AMF: Normal AMF operation
MRS: When MRS mode is selected the controller will not perform AMF functions anymore. MCB
button will be inactive and also mains measurement and protections will be disabled. The
controller will keep TEST mode and the genset in AUT mode will be able to start by Rem
Start/Stop binary input.
Hint:
When the AMF controller operates in MRS mode and detects voltage on Mains terminals Wrn MainsV
Det. is displayed in Alarm list.
SLAVE/MASTER:
When SLAVE or MASTER is selected the controller will perform Dual Mutual Standby function.
Hint:
MASTER or SLAVE can be also defined by binary input DualAMFRole with higher priority than
Operation Mode setpoint.
DualAMFTime [h]
Within this time period are gen-sets switching in supplying the load.
Step: 1h
Range: 1 – 24h
RetFromIsland [MANUAL / AUTO]
MANUAL: After closing GCB, IL goes to MAN Mode automatically.
AUTO: No automatic switching to MAN Mode.
EmergStart Del [s]
Delay after the mains failure to the start of the gen-set
Step: 1s
Range: 0 – 6000 s
MainsReturnDel [s]
Delay after the mains return to the GCB opening.
Step: 1s
Range: 1 – 3600 s
MFB MReturnDel [s]
Delay after the mains return to the GCB opening in case BI: MainsFailBlock is active .
Step: 1s
Range: 1 – 3600 s
