Step: 1s
Range: 1 – 300 (Max Stab Time) s
Max Stab Time [s]
Maximum time after start to get proper voltage level of the generator.
Step: 1s
Range: 1 (Min Stab Time) – 300 s
Hint:
When generator voltage within Max Stab Time does not reach defined limits (Generator protection
group) , an alarm occurs and the gen-set will shut down
Cooling Speed [IDLE / NOMINAL]
Selects the function of the binary output IDLE/NOMINAL during engine Cooling state.
NOMINAL : Cooling is executed at Nominal speed and generator protections are active.
IDLE: Cooling is executed at Idle speed and generator protections are switched off.
Hint:
Binary output IDLE/NOMINAL must be configured and connected to speed governor. Engine Idle
speed must be adjusted on speed governor
Cooling Time [s]
Runtime of the unloaded gen-set to cool the engine before stop.
Step: 1s
Range: 0 – 3600 s
Hint:
Cooling is executed at nominal speed and generator protections are active.
Stop Time [s]
Under normal conditions the engine must certainly stop within this period. The period starts by issuing
stop command.
Step: 1s
Range: 0 – 600 s
Hint:
Stop of engine is detected when all following conditions are met: RPM <2, Oil pressure < Starting Oil P
Generator voltage < 10 VAC and D+ input isn’t active.
Stop fail is detected when there is difference between those conditions, e.g RPM<2 and Generator
voltage > 10V.
Fuel Solenoid [DIESEL / GAS / EFuelFPmp]
Determines behavior of the binary output FUEL SOLENOID.
DIESEL: The output closes 1 sec before binary output STARTER. The output opens if Emergency
Stop comes or Cooled gen-set is stopped and in pause between repeated starts.
GAS: The output closes together with binary output IGNITION if RPM is over the 30 RPM (fix
value).The output opens after stop command or in pause between repeated start.
EFuelFPmp:When starting, running, stopping, shutting down, etc. it behaves the same way as Fuel
Solenoid: DIESEL, except following situations:
- the output closes
a) at the beginning of prestart or
b) in MAN mode when the gen-set is stopped and STOP button is pressed
(..and in the same cases as Fuel Solenoid: DIESEL)
- the output opens
