InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 75
AMF26-P-2.4 Reference Guide.pdf
Hint:
There are three conditions for stop cranking: Starting RPM, Starting Oil P and D+ (when enabled).
Starter goes off when any of these conditions is vaid.
Prestart Time [s]
Time of closing of the Prestart output prior to the engine start.
Set to zero if you want to leave the output Prestart open.
Step: 1s
Range: 0 – 600 s
Hint:
Set Prestart time >=1 when using PREHEATING binary input or Preheating within Deutz EMR2 ECU.
MaxCrank Time [s]
Maximum time limit of cranking.
Step: 1s
Range: 1 – 60 s
CrnkFail Pause [s]
Pause between Crank Attempts.
Step: 1s
Range: 5 – 60 s
Crank Attempts [-]
Max number of Crank Attempts.
Step: 1
Range: 1 – 10
Idle Time [s]
Idle time delay starts when RPM exceeds Starting RPM. Start fail is detected when during Idle state
RPM decreases below 2.
During the Idle time timer running the binary output IDLE/NOMINAL is opened when it elapses the
IDLE/NOMINAL output closes. Binary output IDLE/NOMINAL opens during Cooling period again.
Step: 1 s
Range: 0 – 600 s
Starting
RPM
R
P
M
BO Starter
BO IDLE/RATED
RPM = 2
R
P
M
Start Fail
Idle Time Min Stab Time
Electric protections
active
Hint:
If the IDLE function not supported on the governor, set the Idle Time nevertheless to minimum 5s to
avoid Underspeed possibly caused by instability of the engine short after start.
Min Stab Time [s]
Minimum time after reaching of defined level of RPM to the closing GCB.
