Once the autodection is successful on gen-set side the chosen configuration is taken as valid configuration
for the Mains side till next gen-set start (when new evaluation is performed) or till the controller is switched
off. In case you need to make new autodetection on Mains side you have to switch off and switch on the
controller.
(Mains status is checked as well till the detection either on Mains side or gen-set side is successfully
finished).
NominalPower1..3 [kW]
Three possible settings of generator nominal power
Step: 1kW
Range: 1 – 5000 kW
Nomin Current1..3 [ A ]
Three different configurations of generator nominal current
Step: 1 A
Range: 1 – 10000 A
NomVoltsPh-N 1..3 [V]
Three different configurations of generator nominal voltage (phase to neutral)
Step: 1V
Range: 80 – 20000 V
NomVoltsPh-Ph1..3 [V]
Three different configurations of generator nominal voltage (phase to phase)
Step: 1V
Range: 138 – 35000 V
Hint:
There is a given ratio between NomVolts Ph-N and NomVolts Ph-Ph, based on ConnectionType setting.
Once you change either NomVolts Ph-N or NomVolts Ph-Ph value, the other value is automatically
recalculated. When you change ConnectionType setpoint new NomVolts Ph-Ph value is calculated based on
NomVolts Ph-N which stays still during switchover between different connection types.
Connect Type 1..3 [3Ph4Wire / 3Ph3Wire / Split Ph / Mono Ph]
Three different configurations of generator nominal voltage (phase to phase)
3Ph4Wire: STAR Connection, 3 phases and neutral - 4 wires,
Three phase “wye” measurement – 3PY
3Ph3Wire: DELTA Connection, 3 Phase without neutral - 3 Wires,
Three phase “delta” measurement – 3PD
Split Phase: DOUBLE DELTA Connection, Split Phase,
Single-phase measurement – 1PH
Mono Phase: MONOPHASE,
Single-phase measurement – 1PH
Hint:
For more details about connection types see Voltage measurement and generator connection types.
Service Timers
ServiceBasicH [h]
It counts down when engine running. If reaches zero, an alarm appears. When the value 9999 is set, than
the maintenance function is disabled and counter does not count. Alarm can be acknowledged from
