InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 164
AMF26-P-2.4 Reference Guide.pdf
Wire crosscut min.0,25 mm
2
Maximal attenuation (at 1 MHz) 2 dB / 100m
Recommended Industrial Automation & Process Control Cables:
BELDEN (see http://www.belden.com):
x 3082A DeviceBus for Allen-Bradley DeviceNet
x 3083A DeviceBus for Allen-Bradley DeviceNet
x 3086A DeviceBus for Honeywell SDS
x 3087A DeviceBus for Honeywell SDS
x 3084A DeviceBus for Allen-Bradley DeviceNet
x 3085A DeviceBus for Allen-Bradley DeviceNet
x 3105A Paired EIA Industrial RS485 cable
LAPP CABLE (see http://www.lappcable.com)
x Unitronic BUS DeviceNet Trunk Cable
x Unitronic BUS DeviceNet Drop Cable
x Unitronic BUS CAN
x Unitronic-FD BUS P CAN UL/CSA
IL-NT RS232 interface (optional card)
Plugs into IL-NT controller COMMUNICATION MODULE port.
Maximal distance 10m
Maximum Speed Up to 57,6 kBd (DIRECT), 38,4kBd Analog
modem, 9,6 kBd digital modem, 57,6 kBd (MODBUS)
Recommend external converter:
ADVANTECH – ADAM 4520: RS232 to RS422/485 converter, DIN rail, automatic RS485 bus
supervision, no external data flow control signals, galvanic isolated.
Recommended internal converter:
ADVANTECH – PCL-745B or PCL745S : Dual port RS422/485 Interface card, automatic RS485 bus
supervision, no external data flow control signals, galvanic isolated
Hint:
For details on all IL-NT extension and communication modules see IL-NT, IC-NT-Accessory Modules
manual.
With SW version IL-NT 1.2 and older, the communication speeds are 19,2kBd (STD/DIRECT),
19,2kBd Analog modem, 9,6 kBd digital modem, 9,6kBd (MODBUS)
IL-NT RS232-485 interface (optional card)
Plugs into IL-NT controller COMMUNICATION MODULE port.
Maximal distance 10m (RS232), 1200m (RS485)
Maximum Speed Up to 57,6 kBd (DIRECT), 38,4kBd Analog
modem, 9,6 kBd digital modem, 57,6 kBd (MODBUS)
Hint:
This module is supported with SW version IL-NT 1.3 and newer.
