InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 166
AMF26-P-2.4 Reference Guide.pdf
Earth Fault Current Protection Input
Number of inputs 1
Nominal input current (from CT) 10mA
Input resistance <11Ω
Max measured current from CT 11mA
Current measurement tolerance 2% from Nominal current
Max peak current from CT 0,15A / 1s
Max continuous current 110 mA
Binary inputs
Number of inputs 7
Input resistance 4,7kΩ
Input range 0-36 VDC
Voltage level for close contact indication (Logical 1) <1,5 VDC
Voltage level for open contact indication (Logical 0) >1,5 VDC
Max voltage level for open contact indication 8-36 VDC
Binary outputs (open collectors)
Number of outputs 7
Maximum current per pin 0,5 A
Maximum switching common current 2 A
Maximum switching voltage 36V
Maximum voltage drop 1V
Hint:
All inputs and outputs are not galvanicaly isolated.
Please see detail about wiring and description at chapter IL-NT-EFCPM2.
IGS-PTM
Voltage supply 8-36V DC
Consumption 0,1A depend on supply voltage
Mechanical dimensions: 40 x 95 x 45 mm , DIN rail (35 mm) mounted
Interface to controller CAN
Binary inputs and outputs see IG-IOM
Analog output see IG-IOM
Analog inputs
Not electrically separated
Number of inputs 4
Resolution 10 bits
Maximal resistance range 0 – 250 :
Maximal voltage range 0 – 100 mV
Maximal current range 0 – 20 mA
Resistance measurement tolerance 1 % r 2 : out of measured value
Voltage measurement tolerance 1,5 % r 1mV out of measured value
Current measurement tolerance 2,5 % r0,5mA out of measured value
IGL-RA15
Power supply
Voltage supply 8-36V DC
Consumption 0,35-0,1A (+1A max horn output)
